Description

1.8 GHz Radio System with Bodypack Transmitter

• Frequency band: 1.8 GHz (1785 – 1800 MHz)
• 1 Bank with 16 memory presets
• Adjustable squelch with Threshold indicator on the receiver
• Frequency scan in the receiver
• Adjustable AF out
• Adjustable transmission power (5 mW, 10 mW, 20 mW)
• Infrared transmission setting from receiver to transmitter
• Pilot tone
• Steps: 25 kHz
• Up to six 1.8 GHz parallel Free Solo transmission paths
• 9.5 “/ 1U Housing with 2 BNC Outputs for antennas
• XLR and Jack outputs
• Operates with 12V 0.5 A DC power supply (+ internal)
• Bodypack transmitter in plastic housing
• 3-Pin TQG male connector
• LCD Display
• Powered by 2 AA batteries or rechargeable batteries (not included)
• Includes: Guitar cable, rack mount and plastic case
• Optional matching antenna converter: Article Nr. 177448 (not included)

30 30-Day Money-Back Guarantee

3 3-Year Thomann Warranty

• Available since January 2014

• Item number 323196

• Sales Unit 1 piece(s)

• Guitar Channels 1

• Transmission Format Analog

• Frequency 1800 MHz

• Transmitter Type Pocket Transmitter

• Receiver Type Stationary

• Mountable Antenna BNC

• Charging System No

• Internal Battery No

• Dante No

• Diversity Yes

• Transmission Power in mW 20 mW

• Usable Frequencies 192

• Switching bandwidth in MHz 0,025 MHz

• Frequency Display Yes

• Automatic Frequency Search Yes

• Battery Status Display Yes

• Transmitter with Accu No

• Output XLR

• Receiver Width in mm 212 mm

• Receiver Height in mm 44 mm

• Receiver Depth in mm 160 mm

• Rackkit Yes

• Receiver Weight in kg 0,9 kg
