Description

USB 2.0 Audio Interface

• 24 Bit / 192 kHz AD/DA converter
• 20 Input and output channels
• SteadyClock FS
• Stand-alone functionality
• DURec feature: built-in digital recorder for all inputs and outputs directly to USB storage devices via the rear USB port (enables recording to USB sticks or hard drives with up to 2 TB capacity)
• TotalMix mixing / routing software
• DigiCheck software
• Class Compliant
• Compatible with optional ARC USB remote control (not included)
• DC-coupled outputs – CV/Gate Voltage Control
• +48 V phantom power
• Colour display
• Housingt type: 9.5″ 1 U
• Dimensions (W x H x D): 215 x 44 x 130 mm
• Weight: 910 g
• Incl. external power supply 100V – 240V AC, 12V 2A DC

Connections:

• 2 Mic/line combo inputs: XLR / 6.3 mm jack
• 2 Instrument/line inputs: 6.3 mm jack
• 4 Line inputs: 6.3 mm jack
• 6 Line outputs: 6.3 mm jack
• Stereo headphone output: 6.3 mm jack
• ADAT input and output
• Word Clock input and output
• AES/EBU and S/PDIF coax
• MIDI input and output
• DUrec USB

30 30-Day Money-Back Guarantee

3 3-Year Thomann Warranty

• Available since July 2021

• Item number 521302

• Sales Unit 1 piece(s)

• Recording / Playback Channels 20×20

• Number of Mic Inputs 2

• Number of Line Inputs 8

• Instrument Inputs 2

• Number of Line Outs 6

• Headphone Outs 1

• Phantom power Yes

• Number of S/PDIF Connectors 1

• Number of ADAT Connectors 1

• Numer of AES/EBU Connectors 1

• Number of MADI Connectors 0

• Ethernet 0

• Other Connectors DUrec USB

• MIDI interface Yes

• Word Clock 1xIn, 1xOut

• Max. sample rate (kHz) 192 kHz

• Max. resolution in bit 24 bit

• USB Bus-Powered No

• Incl. power supply Yes

• USB Version 2.0

• Width in mm 215 mm

• Depth in mm 130 mm

• Height in mm 44 mm

• Connection Format USB port Type B

• Included in delivery USB cable, breakoutcable, software

• Zero latency monitoring Yes
