Description

EBS MultiComp True Dual Band Compressor
The EBS MultiComp is a super easy compressor to dial in. One knob sets the level of Comp/Limit. Another sets the Gain level. Once you find the right levels of compression and gain, you can choose Tubeism, Multi Band (MB), or Normal for three distinct types of compression. Done! If you play a bass with very high output, there is an Active/Passive switch on the side to reduce the input level. For those with that engineers degree that like to fiddle around with their equipment, theres an internal trim pot for the Threshold located under the hood too.

Specifications

Nominal Input Level: -10 or -4 dBv

Input Impedance: 1.8 Mohms

Bandwidth: +0/-3 dB: 20 – 20k Hz

Gain Range: 0 – 15 dB (makeup)

Compressor Ratio min/max: 1:1 – 5:1

Sensitivity Range (Threshold): -25 – +6 dB

Attack Time (80 ):

Release Time (80 ): typ. 100 ms

Type: Analog Effect, Relay type Switching

Power Requirements: 9, 12 or 18 V DC, 45 mA max. Pedal shuts off below 6.0 V (power plug not included)

Dimensions (W x H x D): 67 x 115 x 48 mm

Weight: 315g

Product code: EBS-MC-BL
