ANTMIX 12FX allows to manage sound in many different applications: a public speaking, a conference, but also more complex applications such as live music. The smart design of the console helps all kind of user to get the most of any audio performance. It represents a smooth solution featuring pro-details such as an advanced internal DSP with different effects and variations, the built-in compressor for main microphone inputs of 12FX, 60 mm faders as well as a series of I/O to fulfill a wide range of applications.
Specifically designed for an immediate and user friendly use, this mixer satisfies the needs of those who want an audio mixer providing excellent performances, wide versatility of connections and controls.
Make the most of any live audio performance
24-bit Digital Sound Processed EFFECTS for the most creative mix
On-board mic preamp for low-noise and more dynamic range
MONO mic/line inputs4 with compressor
Mic mono/stereo line inputs2
Stereo line input2
Dimensions (W x H x D)340 x 100 x 416 mm
Weight3,53 Kg
MICROPONE INPUT
ConnectorBalanced XLR
Impedance1.8 kΩ
Frequency response20~20kHz +/-1dB
Distortion (THD + N)<0,03% @ +0dB, 22~22 kHz, A weighted
Gain0~55dB
Max input+15dB (balanced)
Low-cut75Hz 12dB/oct.
Signal-to-noise ratio<-100 dBr A weighted
Phantom powering+48V
LINE INPUT
Connector Balanced6,35mm (1/4”) – unbalanced RCA
Impedance10 kΩ
Frequency response20~20kHz +/-1dB
Distortion (THD + N)<0,03% @ +0dB, 22~22 kHz, A weighted
Gain+15dB~-35dB
Signal-to-noise ratio<-100 dBr weighted A
COMMON SPECIFICATION
Compressor<7br> only for channels featuring this control)Gain: 0 —> 9 dB | Soglia: 20 dB —> 5 dB
Hum & noise< -80dB (A weighted, full bandwidth, 1 channel and MAIN @ 0dB, other chan- nels @ minimum)
Crosstalk< -80dB (A weighted, full bandwidth, 1 channel and MAIN @ 0dB, other chan- nels @ minimum)
EQUALIZATION AND 2-TRACK IN
Mono & mono/stereo channels+/-15 dB @12 kHz / +/-15 dB @2.5 kHz /+/-15 dB @80 Hz+/-15 dB @12 kHz +/-15 dB @2.5 kHz / +/-15 dB @80 Hz +/-15 dB @12 kHz / +/-15 dB @2.5 kHz+/- 15 dB @80 Hz
Stereo channels+/-15 dB @12 kHz / +/-15 dB @80 Hz+/-15 dB @12 kHz +/-15 dB @80 Hz+/-15 dB @12 kHz / +/-15 dB @80 Hz
MICROPHONE INPUT
Connector2 x unbalanced RCA
Impedance10 kΩ
Frequency response20~20kHz +/-1dB
Distortion (THD + N)<0,03% @ +0dB, 22~22 kHz, A weighted
GainOFF~+15dB
STEREO RETURNS
Connector2 x balanced 6,35mm (1/4”)
Impedance10 kΩ
Frequency response20~20kHz +/-1dB
Distortion (THD + N)<0,03% @ +0dB, 22~22 kHz, A weighted
GainOFF~+15dB
DSP
A/D – D/A converters24 bit
Number of e ects16 for 6FX – 100 for 8Fx and 12FX
ControlsPresets rotary selector – 16 position (6FX) or 100 position (8FX & 12FX) DFX MUTE footswitch / DFX MUTE switch / DFX button (only 8FX & 12FX) Presets rotary selector – 16 position (6FX) or 100 position (8FX & 12FX) DFX MUTE footswitch / DFX MUTE switch / DFX button (only 8FX & 12FX)
OUTPUTS
MAIN MIX connectors2 x TRS 6,35mm (1/4”) connector (XLR in 12FX)
MAIN MIX max output level+22 dBu XLR balanced (+16 dBu unbalanced)
MAIN MIX output impedance120 Ω
GR1-2 in connectors (12FX only)2 x TRS balanced 6,35mm (1/4”)
GR1-2 max output level (12FX only)+22 dBu XLR balanced (+16 dBu unbalanced)
GR1-2 output impedance (12FX only)120 Ω
Headphones connectorUnbalanced TRS 6,35mm (1/4”)
Headphones impedance30 Ω
Control room connectors2 x balanced TRS 6,35mm (1/4”)
Control room impedance120 Ω
2-TK connectors2 x unbalanced RCA
2-TK impedance1 kΩ
