Description

Compact Bluetooth Digital Mixer with 7″ Touch Screen

• 96 kHz Signal processing
• Control via Windows, Mac, Android and iOS possible (Apps: CQ-MixPad and CQ4You)
• Dual band router 2.4/5 GHz network
• USB sound card (in/out) 24×22 (USB-B)
• SD-card player/reorder (in/out) 24×22 SD-card recording/playback
• Stereo USB recorder/player (USB-A)
• Bluetooth stereo playback
• Gain/feedback assistant (automatic preamplifier adjustment)
• 4 FX Assist Engines
• 3x Smart Rotaries
• 3 User-defined SoftKeys
• Connection for dual foot switch
• Dimensions (W x H x D): 346 x 88 x 242 mm
• Weight: 3 kg
• Suitable rackmount: Art. 573739 (not included)
• Suitable case: Art. 573740 (not included)

Inputs:

• 16x Mic/line preamp (8x XLR + 8x XLR/TRS combo jack)
• 1x Stereo line (balanced)

Outputs:

• Main 2 XLR
• 6x Monitor Out (TRS)
• 2x 6.30 mm headphone output (TRS)

30 30-Day Money-Back Guarantee

3 3-Year Thomann Warranty

• Available since September 2023

• Item number 573741

• Sales Unit 1 piece(s)

• User Interface Physical/remote

• Number of faders 0

• DSP Input channels 18

• Mic Preamp 16

• Physical outputs 8

• Digital stagebox connection No

• Hotspot No

• Multitrack Record Yes

• integratated Player/Rec via USB/SD Multitrack

• 19″ Rackmount Optional

• DSP Output Channels 8

• Busses 6

• Mono-Line Input 5

• Stereo-Line Input 1

• Ethernet Ethernet

• Soundcard interface USB-B

• Recorder Format WAV

• Scribble Strips Yes

• RTA No

• FX Processor 4

• 31 Band EQ 0

• Matrix 0

• Midi Connector No

• Sample rate 96 kHz

• Monitor Apps Yes

• Separate Personal Monitor system No

• Expansion Card slots 0

• Digital ADAT No

• Digital SPDIF No

• Digital AES3/ASESEB No

• Digital MADI No

• Digital Dante No

• Case Optional

• Height 88 mm

• Width 346 mm

• Depth 242 mm

• Weight 3 kg
