Description

ADK STUDIO-HAMBURG MK8

The ADK Hamburg Mk8 Large Diaphragm Condenser Microphone is a new and upgraded version of the popular Hamburg Edition with a More Fine-Tuned Response-Curve Designed to Replicate a Vintage Late 1950’s German Tube (Valve) Mic. The Hamburg Mk 8 is the Eighth Generation of ADK Microphones – offering a Mellow, Robust Tonality.

Standard Configuration: The Mic, Piano-Black Wooden Jewel Case, and Heavy-Duty All-Metal Ring-Mount.

The Hamburg Favors “Crooner” Vocals or Ballads, Classical, Folk, Jazz Singers; Reeds.

Applications: Very Useful for Vocals or Sources needing a Rounder Tone. For Strings, Reeds, Nasal or Thin Vocals, or Vocals with Sibilance Issues – the Hamburg Will Work Wonders! Hamburgs have “Smoothness”, Historically the Classic German Tone.

The Hamburg has a robust quality that tends to round-out the tone of the source. It’s great on vocals, reeds, or bass elements.

ADK Hamburg Mk8 Large Diaphragm Condenser Microphone Features

5 MICRON 1.07” diaphragm capsule

High SPL handling (126dB Max SPL)

Class A Electronics

Fixed-Cardioid polar pattern

14dB Pad

High-Pass Filter

ADK Hamburg Mk8 Large Diaphragm Condenser Microphone Specifications

Type: Class A Pressure Gradient FET Condenser Microphone

Polar Pattern: Fixed Cardioid

Sensitivity: 15mv/Pa

Impedance: 200Ohm

S/N Ratio: 81dB (Ref: 1 Pa / A-Weighted)

Equivalent Self-Noise: 15dB (A-Weighted / IEC 268-4)

Max SPL @ 0.5% THD: 126dB / 140dB (0dB/-14dB Switchable PAD)

Total Dynamic Range: 125 dB

Low-Cut Filter (HPF): Flat / 89Hz

Power Requirement: Phantom Power 48V ± 4V
